GROUP METERING PANELS

GROUP METERING PANELS

Rigid welded construction

IP56 weatherproof

Pad lockable 3 Point locking system

Removable type X panel AS1795

Powder coated grey RAL 7035

Complete with cable tray and gear pan

Can be supplied empty or 100% wired

3 sizes available

We also have a full  range of group

meter enclosures suitable for

high rise, please call for more details.

Part No – GMP-9

Enclosure 700w x 1420h x 400d mm

9 Single phase meters

6 Three phase meters

30 poles of din space

Part No GMP-12

Enclosure 1380w x 1070h x 400d mm

12 Single phase meters

8 Three phase meters

60 poles of din space

Part No – GMP 18

Enclosure 1380w x 1420h x 400d mm

18 Single phase meters

12 Three phase meters

60 poles of din space

Now Available in Plinth Mounted
